Description
Buy WISKA 10106226 QUIXX EMT-F membrane grommet kit. Flame-retardant IP66 cable entry kit containing 20mm, 25mm and 32mm membrane entries in white.
Fast UK Delivery.
Product Code:
10106226
Brand:
WISKA
Colour:
White
The WISKA 10106226 EMT-F Kit is a flame-retardant membrane cable entry solution designed for creating secure cable entries into electrical enclosures.
Part of the WISKA QUIXX range, the kit contains 14 membrane entries across three commonly used sizes: 8 x EMT-F 20, 3 x EMT-F 25 and 3 x EMT-F 32.
The membrane entries provide IP66 protection and offer a practical cable entry solution for applications including consumer units, distribution equipment and electrical enclosures.
Manufactured from flame-retardant material, the EMT-F entries have been glow-wire tested to 960°C and are suitable for operating temperatures from -40°C to +80°C.
KEY FEATURES
WISKA QUIXX EMT-F membrane grommet kit
14 membrane cable entries included
8 x EMT-F 20 – 20mm
3 x EMT-F 25 – 25mm
3 x EMT-F 32 – 32mm
Flame-retardant construction
IP66 protection rating
White finish
960°C glow-wire tested
Operating temperature: -40°C to +80°C
Three common cable entry sizes in one kit
Part of the WISKA QUIXX cable entry range
Additional Information
Kit Contents: 8 x 20mm, 3 x 25mm, 3 x 32mm
Total Quantity: 14
Protection Rating: IP66
Colour: White
Temperature Range: -40°C to +80°C
Glow Wire Test: 960°C
ETIM Classification: EC000451
