Description
Buy GEWISS GW70488P 25A 4 pole rotary isolator switch. Heavy-duty enclosed emergency isolator with lockable red handle and IP66/IP67/IP69 protection.
Fast UK Delivery.
Product Code:
GW70488P
Brand:
GEWISS
Colour: Yellow /
Grey / Red
The GEWISS GW70488P is a 25A 4 pole enclosed rotary isolator designed to provide safe and secure electrical isolation in residential, commercial and industrial installations.
Part of the GEWISS 70 RT HP range, this emergency-version isolator features a red rotary handle that can be padlocked in the OFF position using up to three padlocks, helping provide secure isolation during maintenance and servicing.
The insulating enclosure provides IP66, IP67 and IP69 protection together with IK08 mechanical impact resistance, making the GW70488P suitable for demanding installation environments.
Rated at 25A for AC-21A, AC-22A and AC-23A operation at 415V, the isolator accepts cable sizes from 1mm² to 10mm² and provides M20/M25 knockout cable entries at both the top and bottom of the enclosure.
KEY FEATURES
25A rotary isolator switch
4 pole configuration
Emergency isolator version
Lockable red rotary handle
Can be padlocked in OFF position
Accepts up to 3 padlocks
IP66 / IP67 / IP69 protection
IK08 mechanical impact resistance
Insulating enclosure
Double insulated
690V rated insulation voltage
25A AC-21A rating at 415V
25A AC-22A rating at 415V
25A AC-23A rating at 415V
10kA conditional short circuit current at 415V
1mm² to 10mm² cable capacity
2 x M20/M25 top knockouts
2 x M20/M25 bottom knockouts
Operating temperature: -25°C to +60°C
Part of the GEWISS 70 RT HP range
Additional Information
Rated Current: 25A
Number of Poles: 4P
Rated Insulation Voltage: 690V AC
AC-21A Rating at 415V: 25A
AC-22A Rating at 415V: 25A
AC-23A Rating at 415V: 25A
Conditional Short Circuit Current: 10kA at 415V
Cable Capacity: 1mm² – 10mm²
Dimensions: 125mm x 150mm x 75.5mm
Protection Rating: IP66 / IP67 / IP69
Impact Rating: IK08
Operating Temperature: -25°C to +60°C
